16-inch x 16-inch Utility Bolt Plate Truss comes in standard lengths of 2', 2.5', 3', 4', 5', 8-foot, and 10-foot with custom lengths available upon request. The chords are 2-inch OD x 1/8-inch thick with 1-inch OD x 1/8-inch thick diagonals. The trusses are joined together with 5/8-inch steel bolts.
Fabricated by AWS certified welders in the USA.
Powder Coating available upon request in most colors.
Anodizing available upon request in select colors.
