Standard Material 6063 - T6 Aluminum
Standard Finish 51- Black Anodized
Available Finish(es) 01- Brush | 20-30 Powder Coated | 50-51 Anodized
Size 6” x 6” x User defined length (152.40mm x 152.40mm x User defined length)
Max length per piece 20’
Weight 10.11lbs (4.59 Kg)/ft* *Weight per foot can vary
Track Size T-Slot: 0.656” x 1.312” (16.67mm x 33.34mm)
Keyway (aka Keder Track or Screw-boss): 10.5mm
Recommended Hardware
ModTruss Nut Bars | ModTruss Insert Nuts | 3” Blind Connector
